SF-JH Automatic fi llet welding car
Classification: Automatic welding car
The welding car adopts 24V battery power supply, especially suitable for field and inconvenient welding occasions.
Product Introduction
Functional characteristics
The welding car adopts 24V battery power supply, especially suitable for field and inconvenient welding occasions.
Can realize the left and right directions of welding, the car is installed at both ends of the induction stop switch, the car can be automatically stopped after the end of welding, easy for a worker to operate multiple equipment.
Small size, light weight, easy to move and install, non-skilled workers can also be welded.
A permanent magnet is installed to prevent the car from leaving the welding line.
It can be mounted on the vertical surface for welding.
Technical parameter
|
trolley |
species |
content |
remark |
|
Power source |
DC24V |
L lithium |
|
|
size |
300*240*270 |
L*W*H |
|
|
weight |
8kg |
|
|
|
Move |
Four-wheel drive |
Rubber wheel |
|
|
Travel speed |
0~980mm/min |
Digital display |
|
|
Welding gun |
Up and down |
±35mm |
|
|
Front and rear |
±35mm |
||
|
Operating Angle adjustment range |
45。 |
||
|
Angle adjustment range |
90。 |
||
|
Controls |
Operating function |
LED digital display |
0~98mm |
|
Start of walk |
activate |
||
|
Walking stop |
stop |
||
|
Choose the direction of travel |
Left and right |
||
|
Adjust walking speed |
Arrow mark |
||
|
|
Select welding/non- welding |
|
