Product
SF-LJ Automatic vertical fi llet welding car
Classification: Automatic welding car
Compact and lightweight: small size, light weight, easy to move and install, non-skilled workers can also be welded.
Product Introduction
Functional characteristics
Compact and lightweight: small size, light weight, easy to move and install, non-skilled workers can also be welded.
The welding car uses battery power supply, especially suitable for fi eld and inconvenient welding occasions.
It is equipped with permanent magnet to avoid the phenomenon of the car leaving the welding line, and the guide wheel can automatically track the welding path.
Magnetic control handle is installed, and the handle is automatically clutch for easy use.
With swing function, suitable for wide and thick weld welding Can automatically adjust the Angle of welding torch 360°
Technical parameter
|
trolley |
species |
content |
remark |
|
Power source |
DC24V-4AH |
Lithium battery |
|
|
size |
280*330*270 |
L*W*H |
|
|
weight |
9.8kg |
|
|
|
Move |
Four-wheel drive |
Rubber wheel |
|
|
|
0~980mm/min |
Digital display |
|
|
Travel speed |
Permanent magnet |
built-in |
|
|
Welding gun |
Up and down |
±15mm |
|
|
Front and rear |
±15mm |
||
|
Operating Angle adjustment range |
45。 |
||
|
Angle adjustment range |
360。 |
||
|
Controls |
Operating function |
Oscillating velocity |
0~98 |
|
Swing Angle |
0~96 |
||
|
Left/right residence time |
0~2.5S |
||
|
Delay residence time |
0~2.5S |
||
|
LED digital display |
|
||
|
Start of walk |
activate |
||
|
Walking stop |
stop |
||
|
Choose the direction of travel |
Left and right |
||
|
Adjust walking speed |
0~98 |
||
|
|
Select welding/non- welding |
Shift switch |
